STT
|
MÃ SẢN PHẨM
|
MÔ TẢ KỸ THUẬT
|
|
|
PLC S7 300 CPU
|
|
|
1
|
6ES7312-1AE13-0AB0
|
SIMATIC S7-300, CPU 312
CPU WITH MPI INTERFACE,
INTEGRATED 24 V DC POWER SUPPLY
32 KBYTE WORKING MEMORY,
MICRO MEMORY CARD NECESSARY
|
|
2
|
6ES7312-5BE03-0AB0
|
SIMATIC S7-300, CPU 312C
COMPACT CPU WITH MPI,
10 DI/6 DO,
2 FAST COUNTERS (10 KHZ),
INTEGRATED 24V DC POWER SUPPLY,
32 KBYTE WORKING MEMORY,
FRONT CONNECTOR (1 X 40PIN) AND
MICRO MEMORY CARD REQUIRED
|
|
3
|
6ES7313-5BF03-0AB0
|
SIMATIC S7-300, CPU 313C,
COMPACT CPU WITH MPI,
24 DI/16 DO, 4AI, 2AO 1 PT100,
3 FAST COUNTERS (30 KHZ),
INTEGRATED 24V DC POWER SUPPLY,
64KBYTE WORKING MEMORY,
FRONT CONNECTOR (2 X 40PIN) AND
MICRO MEMORY CARD REQUIRED
|
|
4
|
6ES7313-6BF03-0AB0
|
SIMATIC S7-300, CPU 313C-2 PTP
COMPACT CPU WITH MPI,
16 DI/16 DO,
3 FAST COUNTERS (30 KHZ),
INTEGRATED INTERFACE RS485,
INTEGRATED 24V DC POWER SUPPLY,
64 KBYTE WORKING MEMORY,
FRONT CONNECTOR (1 X 40PIN) AND
|
|
5
|
6ES7313-6CF03-0AB0
|
SIMATIC S7-300, CPU 313C-2DP
COMPACT CPU WITH MPI,
16 DI/16 DO,
3 FAST COUNTERS (30 KHZ),
INTEGRATED DP INTERFACE,
INTEGRATED 24V DC POWER SUPPLY,
64 KBYTE WORKING MEMORY,
FRONT CONNECTOR (1 X 40PIN) AND
|
|
6
|
6ES7314-1AG13-0AB0
|
SIMATIC S7-300, CPU 314
CPU WITH MPI INTERFACE,
INTEGRATED 24V DC POWER SUPPLY,
96 KBYTE WORKING MEMORY,
MICRO MEMORY CARD NECESSARY
|
|
7
|
6ES7314-6BG03-0AB0
|
SIMATIC S7-300, CPU 314C-2 PTP
COMPACT CPU WITH MPI,
24 DI/16 DO, 4AI, 2AO, 1 PT100,
4 FAST COUNTERS (60 KHZ),
INTEGRATED INTERFACE RS485,
INTEGRATED 24V DC POWER SUPPLY,
96 KBYTE WORKING MEMORY,
FRONT CONNECTOR (2 X 40PIN) AND
|
|
8
|
6ES7314-6CG03-0AB0
|
SIMATIC S7-300, CPU 314C-2DP
COMPACT CPU WITH MPI,
24 DI/16 DO, 4AI, 2AO, 1 PT100,
4 FAST COUNTERS (60 KHZ),
INTEGRATED DP INTERFACE,
INTEGRATED 24V DC POWER SUPPLY,
96 KBYTE WORKING MEMORY,
FRONT CONNECTOR (2 X 40PIN) AND
|
|
9
|
6ES7315-2AG10-0AB0
|
SIMATIC S7-300, CPU 315-2DP
CPU WITH MPI INTERFACE
INTEGRATED 24 V DC POWER SUPPLY
128 KBYTE WORKING MEMORY
2. INTERFACE DP-MASTER/SLAVE
MICRO MEMORY CARD NECESSARY
|
|
10
|
6ES7315-2EH13-0AB0
|
SIMATIC S7-300 CPU 315-2 PN/DP,
CENTRAL PROCESSING UNIT WITH
256 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE ETHERNET PROFINET,
MICRO MEMORY CARD NECESSARY
|
|
11
|
6ES7315-2FH13-0AB0
|
SIMATIC S7-300 CPU315F-2 PN/DP,
CENTRAL PROCESSING UNIT WITH
256 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE ETHERNET PROFINET,
MICRO MEMORY CARD NECESSARY
USEABLE WITH SOFTWARE OPTION
S7 DISTRIBUTED SAFETY
|
|
12
|
6ES7315-6FF01-0AB0
|
SIMATIC S7-300, CPU 315F
CENTRAL UNIT FOR S7-300F,
192 KB WORKING MEM., 40MM WIDE,
384 BYTES PAE/384 BYTES PAA,
2 INTERFACES: 1 MPI UND 1 DP
INTEGRATED 24V DC POWER SUPPLY,
MICRO MEMORY CARD REQUIRED
|
|
13
|
6ES7315-6TH13-0AB0
|
SIMATIC S7-300, CPU 315T-2 DP,
CENTRAL PROCESSING UNIT FOR
PLC AND TECHNOLOGY
256 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S
2. INTERFACE DP(DRIVE),
INTEGRATED I/O FOR TECHNOLOGY
FRONT CONNECTOR (1 X 40PIN) AND
|
|
14
|
6ES7317-2AJ10-0AB0
|
SIMATIC S7-300, CPU 317-2DP,
CENTRAL PROCESSING UNIT WITH
512 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE DP-MASTER/SLAVE,
MICRO MEMORY CARD NECESSARY
|
|
15
|
6ES7317-2EK13-0AB0
|
SIMATIC S7-300 CPU 317-2 PN/DP,
CENTRAL PROCESSING UNIT WITH
1 MB WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE ETHERNET PROFINET,
MICRO MEMORY CARD NECESSARY
|
|
16
|
6ES7317-2FK13-0AB0
|
SIMATIC S7-300 CPU317F-2 PN/DP,
CENTRAL PROCESSING UNIT WITH
1024 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE ETHERNET PROFINET,
MICRO MEMORY CARD NECESSARY
FOR USE WITH SOFTWARE OPTION
S7 DISTRIBUTED SAFETY
|
|
17
|
6ES7317-6FF03-0AB0
|
SIMATIC S7-300, CPU 317F-2DP,
CENTRAL PROCESSING UNIT WITH
1024 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE DP-MASTER/SLAVE,
MICRO MEMORY CARD NECESSARY
FOR USE WITH SOFTWARE OPTION
S7 DISTRIBUTED SAFETY
|
|
18
|
6ES7317-6TK13-0AB0
|
SIMATIC S7-300, CPU 317T-2 DP,
CENTRAL PROCESSING UNIT FOR
PLC AND TECHNOLOGY
1024 KBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S
2. INTERFACE DP(DRIVE),
INTEGRATED I/O FOR TECHNOLOGY
FRONT CONNECTOR (1 X 40PIN) AND
|
|
19
|
6ES7318-3EL00-0AB0
|
SIMATIC S7-300 CPU 319-3 PN/DP,
CENTRAL PROCESSING UNIT WITH
1,4 MBYTE WORKING MEMORY,
1. INTERFACE MPI/DP 12MBIT/S,
2. INTERFACE DP-MASTER/SLAVE,
3. INTERFACE ETHERNET PROFINET,
MICRO MEMORY CARD NECESSARY
|
|
|
|
|
|
