STT
|
MÃ SẢN PHẨM
|
MÔ TẢ KỸ THUẬT
|
|
|
MODULE S7 300
|
|
|
1
|
6ES7321-1BH02-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
16DI, 24 V DC, 1 X 20 PIN
|
|
2
|
6ES7321-1BH10-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, GALVANICALLY ISOLATED,
16DI, 24 V DC, 1 X 20 PIN,
0.05 MS INPUT DELAY
|
|
3
|
6ES7321-1BH50-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED
16DI, 24 V DC, SOURCE INPUT,
1 X 20 PIN
|
|
4
|
6ES7321-1BL00-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED
32DI, 24 V DC, 1 X 40 PIN
|
|
5
|
6ES7321-1BP00-0AA0
|
SIMATIC S7-300 DIGITAL INPUT
SM321, OPTICALLY ISOLATED
IN GROUPS OF 16,
64 DI,DC 24V, 3MS,
SINKING/SOURCING
TERMINAL BLOCKS
6ES7392-1.N00-0AA0 AND
CABLES 6ES7392-4...0-0AA0
|
|
6
|
6ES7321-1CH00-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
16 DE, AC/DC 24 - 48V WITH
ONE CHANNEL PER COMMON,
1 X 40 PIN
|
|
7
|
6ES7321-1CH20-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
16 DI, DC 48-125V, 1 X 20 PIN
|
|
8
|
6ES7321-1EL00-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
32 DI, 120V AC, 1 X 40 PIN
|
|
9
|
6ES7321-1FF01-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
8 DI, 120V/230V AC, 1 X 20 PIN
|
|
10
|
6ES7321-1FF10-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
8 DI, 120V/230V AC, 1 X 40 PIN,
WITH 1 POINT PER COMMON
|
|
11
|
6ES7321-1FH00-0AA0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED
16 DI, 120/230V AC, 1 X 20 PIN
|
|
12
|
6ES7321-7BH01-0AB0
|
SIMATIC S7-300, DIGITAL INPUT
SM 321, GALVANICALLY ISOLATED,
16 DI, DC 24V, 1 X 20 PIN,
PROCESS INTERRUPT, DIAGNOSTICS,
FIT FOR ISOCHRONE MODE
|
|
13
|
6ES7321-7RD00-0AB0
|
SIMATIC S7, DIGITAL INPUT
SM 321, OPTICALLY ISOLATED,
4 DI, 24V DC, NAMUR/DIN 19234,
F. SIGNALS F HAZARDOUS AREAS,
CAPABLE OF DIAGNOST.,PTB-TESTED
|
|
14
|
6ES7322-1BF01-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO, 24V DC, 2A, 1 X 20 PIN
|
|
15
|
6ES7322-1BH01-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
16 DO, 24V DC, 0.5A, 1 X 20 PIN
SUM OF OUTPUT CURRENTS 4A/GROUP
(8A/MODULE)
|
|
16
|
6ES7322-1BH10-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322 HIGH SPEED,
GALVANICALLY ISOLATED,
16 DO, 24V DC, 0.5A, 1 X 20 PIN
|
|
17
|
6ES7322-1BL00-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
32DO, 24V DC, 0.5A, 1 X 40 PIN,
SUM OF OUTPUT CURRENTS 4A/GROUP
(16A/MODULE)
|
|
18
|
6ES7322-1FL00-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
32 DO, AC 120V/230V, 1A, DOUBLE
WIDTH HOUSING, 2 X 20 PIN
|
|
19
|
6ES7322-1BP50-0AA0
|
SIMATIC S7-300 DIGITAL OUTPUT
SM322, OPTICALLY ISOLATED
IN GROUPS OF 16,
64DO, DC 24V, 0.3A M-WRITE
TOTAL CURRENT 2A/GROUP
8A/MODULE
TERMINAL BLOCKS
6ES7392-1.N00-0AA0 AND
|
|
20
|
6ES7322-1CF00-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO, DC 48-125V, 1.5A,
1 X 20 PIN
|
|
21
|
6ES7322-1FF01-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO, 120/230V AC, 1A,
1 X 20 PIN
|
|
22
|
6ES7322-1FH00-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 321, OPTICALLY ISOLATED
16 DO, 120/230V AC, 1 A,
1 X 20 PIN
|
|
23
|
6ES7322-1FL00-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
32 DO, AC 120V/230V, 1A, DOUBLE
WIDTH HOUSING, 2 X 20 PIN
|
|
24
|
6ES7322-1HF01-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO (RELAY), 1 X 20 PIN,
24V DC, 2A OR 230V AC, 2A
|
|
25
|
6ES7322-1HF10-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO (RELAY), 1 X 40 PIN,
24V DC, 5A OR 230V AC, 5A,
CONNECTOR W.SPRING TERMINAL CAN
BE USED FROM 6ES7392-1BM01-0AA0
|
|
26
|
6ES7322-1HH01-0AA0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED
16DO, RELAY CONTACTS,
1 X 20 PIN
|
|
27
|
6ES7322-5FF00-0AB0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO, 120/230V AC, 2A,
WITH 1 POINT PER COMMON AND
SELECTABLE FAIL MODE,
1 X 40 PIN
|
|
28
|
6ES7322-5GH00-0AB0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
16 DA (SOLID STATE RELAY),
AC/DC 24 - 48V; 0.5A;
1.5A SURGE CURRENT, ONE CHANNEL
PER COMMON, 1 X 40 PIN
|
|
29
|
6ES7322-5HF00-0AB0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO (RELAY), 1 X 40 PIN,
24V DC, 120 - 230V AC, 5A WITH
INTEGR. SNUBBER F. IND. LOADS
|
|
30
|
6ES7322-5RD00-0AB0
|
SIMATIC S7, DIGITAOUTPUTL
SM 322, OPTICALLY ISOLATED,
4 DO, 15V / 20MA, 1 X 20 PIN,
FOR SIGNALS FROM HAZARDOUSAREAS
CAPABLE OF DIAGNOST.,PTB-TESTED
|
|
31
|
6ES7322-5SD00-0AB0
|
SIMATIC S7, DIGITAOUTPUTL
SM 322, OPTICALLY ISOLATED,
4 DO, 24V DC, 10MA, 1 X 20 PIN,
FOR SIGNALS FROM HAZARDOUSAREAS
CAPABLE OF DIAGNOST.,PTB-TESTED
|
|
32
|
6ES7322-8BF00-0AB0
|
SIMATIC S7-300, DIGITAL OUTPUT
SM 322, OPTICALLY ISOLATED,
8 DO, 24V DC, 0.5 A (1 X 8 DO),
SHORT-CIRCUIT PROTECTION,
DIAGNOSTICS, 1 X 20 PIN
|
|
33
|
6ES7323-1BH01-0AA0
|
SIMATIC S7-300, DIGITAL MODULE
SM 323, OPTICALLY ISOLATED,
8 DI AND 8 DO, 24V DC, 0.5A
AGGREGATE CURRENT 2A, 1X20 PIN
|
|
34
|
6ES7323-1BL00-0AA0
|
SIMATIC S7-300, DIGITAL MODULE
SM 323, OPTICALLY ISOLATED,
16 DI AND 16 DO, 24V DC, 0.5A,
AGGREGATE CURRENT 4A, 1X40 PIN
|
|
35
|
6ES7326-1RF00-0AB0
|
SIMATIC S7, DIGITAL INPUT
SM 326, 8 DI; DC 24V, NAMUR,
FAILSAFE NAMUR INPUTS
FOR SIMATIC S7F SYSTEMS,
1 X 40 PIN
|
|
36
|
6ES7326-2BF01-0AB0
|
SIMATIC S7, DIGITAL OUTPUT
SM 326, 10 DO; 24V DC, 2A,
FAILSAFE DIGITAL OUTPUT
FOR SIMATIC S7F SYSTEMS WITH
DIAGNOST. INTERRUPT,
1 X 40 PIN
|
|
37
|
6ES7327-1BH00-0AB0
|
SIMATIC S7-300, DIGITAL MODULE
SM 327, OPTICALLY ISOLATED,
8 DI AND 8 DX, 24V DC, 0.5A
1 X 20 PIN,
8DX CHANNELWISE
PROGRAMMABLE AS DI OR DO
|
|
38
|
6ES7331-1KF01-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPTICALLY ISOLATED,
8 AI, 13 BIT RESOLUTION,
U/I/RESISTANCE/PT100,
NI100, NI1000, LG-NI1000,
66 MS MODULE UPDATE,
1 X 40 PIN
|
|
39
|
6ES7331-7HF01-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, GALVANICALLY ISOLATED,
8 AI, 14 BIT, 0.052MS/CHANNEL,
CURRENT, VOLTAGE, INTERRUPTS,
DIAGNOSTICS,1 X 20 PIN,
FIT FOR ISOCHRONE MODE
IMPROVED DP-CYCLE TIME FOR
ISOCHRONE MODE
|
|
40
|
6ES7331-7KB02-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPTICALLY ISOLATED,
2 AI, 9/12/14 BITS RESOLUTION,
U/I/THERMOCOUPLE/RESISTANCE,
INTERRUPT, DIAGNOSTICS,
1 X 20 PIN,
REMOVE/INSERT W. BACKPLANE BUS
|
|
41
|
6ES7331-7KF02-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPTICALLY ISOLATED,
8AI, RESOLUTION 9/12/14 BITS,
U/I/THERMOCOUPLE/RESISTANCE
INTERRUPT, DIAGNOSTICS; 1X20PIN
REMOVE/INSERT W. BACKPLANE BUS
|
|
42
|
6ES7331-7NF00-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPTICALLY ISOLATED,
8 AE; +/-5/10V, 1-5 V, +/-20MA,
0/4 TO 20MA, 16 BIT (55 MS),
1 COMMON POINT(50 V COM.),
1 X 40 PIN
|
|
43
|
6ES7331-7NF10-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPTICALLY ISOLATED,
8 AE; +/-5/10V, 1-5 V, +/-20MA,
0/4 TO 20MA, 16 BIT,
1 COMMON POINT(60 V COM.),
4 CHANNEL MODE: 10 MS,
8 CHANNEL MODE: 23-95 MS,
1 X 40 PIN
|
|
44
|
6ES7331-7PF01-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPT. ISOL.,2/3/4 WIRE,
8AI, RESISTANCE, PT100/200/1000
NI100/120/200/500/1000, CU10,
PLUS CHARACTERISTICS ACCORDING
TO GOST STANDARD
16 (INTERN 24) BIT, 50MS,
1 X 40 PIN
|
|
45
|
6ES7331-7PF11-0AB0
|
SIMATIC S7-300, ANALOG INPUT
SM 331, OPTICALLY ISOLATATED,
8 AI THERMOCOUPLE,
TYPE B, E, J, K, L, N, R, S, T
TXK/TXK(L) ACCORDING GOST
16 BIT, 50 MS, 1 X 40 PIN
|
|
46
|
6ES7331-7RD00-0AB0
|
SIMATIC S7, ANALOG INPUT
SM 331, OPTICALLY ISOLATATED,
4 AI, 0/4 - 20MA, 1 X 20 PIN,
F. SIGNALS F. HAZARDOUS AREAS,
CAPABLE OF DIAGNOST.,PTB-TESTED
|
|
47
|
6ES7331-7SF00-0AB0
|
SIMATIC S7, ANALOG INPUT
SM 331, OPTICALLY ISOLATATED,
8 AI THERMOCOUPLE/4 AI PT100,
F. SIGNALS F. HAZARDOUS AREAS,
CAPABLE OF DIAGNOST.,PTB-TESTED
1 X 20 PIN
|
|
48
|
6ES7332-5HB01-0AB0
|
SIMATIC S7-300, ANALOG OUTPUT
SM 332, OPTICALLY ISOLATED,
2 AO, U/I; 11/12 BITS RESOL.,
20 PIN., REMOVE/INSERT WITH
ACTIVE BACKPLANE BUS
|
|
49
|
6ES7332-5HD01-0AB0
|
SIMATIC S7-300, ANALOG OUTPUT
SM 332, OPTICALLY ISOLATED,
4 AO, U/I; DIAGNOSTICS;
RESOLUTION 11/12 BITS, 20 PIN,
REMOVE/INSERT W. ACTIVE,
BACKPLANE BUS
|
|
50
|
6ES7332-5HF00-0AB0
|
SIMATIC S7-300, ANALOG OUTPUT
SM 332, OPTICALLY ISOLATED,
8 AO, U/I; DIAGNOSTICS;
RESOLUTION 11/12 BITS, 40 PIN,
REMOVE/INSERT W. ACTIVE,
BACKPLANE BUS
|
|
51
|
6ES7332-5RD00-0AB0
|
SIMATIC S7, ANALOG OUTPUT
SM 332, OPTICALLY ISOLATED,
4 AO, 0/4 UP TO 20 MA, 20 PIN,
FOR SIGNALS FROM HAZARDOUSAREAS
CAPABLE OF DIANOST., PTB-TESTED
|
|
52
|
6ES7332-7ND02-0AB0
|
SIMATIC S7,SM 332 ANALOG OUTPUT
CHANNEL TO CHANNEL ISOLATION,
4 AO, 16 BIT RESOLUTION,
0-10V, 1-5V, +/-10V, +/-20MA,
0/4 - 20MA, 20 PIN,
FIT FOR ISOCHRONE MODE
IMPROVED DP-CYCLE TIME FOR
ISOCHRONE MODE
|
|
53
|
6ES7334-0CE01-0AA0
|
SIMATIC S7, ANALOG INPUT/OUTPUT
SM 334, NON-ISOLATED,
4 AI/2 AO, 1 X 20 PIN,
REMOVE AND INSERT WITH
BACKPLAIN BUS
|
|
54
|
6ES7334-0KE00-0AB0
|
SIMATIC S7-300, ANALOG MODULE
SM 334, OPTICALLY ISOLATED,
4AE/2AA, 12 BIT, 0-10V F. PT100
(CLIMAT RANGE -120 - 155 DEGR.)
AND 10 KOHM MEASURING RANGE,
1 X 20 PIN
|
|
55
|
6ES7336-4GE00-0AB0
|
SIMATIC S7, ANALOG INPUT SM336
6 AI; 15 BIT; 1 X 20 PIN,
FAILSAFE ANALOG INPUTS
SIL 3, FOR SIMATIC SAFETY,
WITH HART SUPPORT
|
|
56
|
6ES7338--4BC01-0AB0
|
SIMATIC S7-300, SIGNAL. MODULE
FOR 3 SSI SENSORS FOR READ-IN
OF POSITIONING VALUE WITH
2 FREEZE INPUTS , 1 X 20 PIN,
SUPPORTS ISOCHRONE MODE
|
|
57
|
6ES7355-0VH10-0AE0
|
SIMATIC S7-300, CONROL MODULE
FM 355 C, 4 CHANNELS, CONTIN.
4 AI + 8 DI + 4 AO
INCL. MULTI-LANG CONFIG. PACK.,
MANUAL AND GETTING STARTED
(GER/EN/FR/IT) ON CD-ROM
|
|
|
|
|
|
